SounDigital 1600.1 EVO 6 - 1 Ohm

  • 2 790 kr
Tillgänglig
Dela
  • Information

The 1600.1 EVO 6 is a compact, modern amplifier that delivers 1600W RMS of power over 1 channel.

The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.

Teknisk information

  • Power @ 4Ω: 1 X 697 WRMS
  • Power @ 2Ω: 1 X 1056 WRMS
  • Power @ 1Ω: 1 X 1600 WRMS
  • Frequency Response (-3dB):
  • 5Hz ~ 25kHz
  • Subsonic Filter:
  • 5Hz ~ 80Hz
  • Low Pass Filter:
  • 50Hz ~ 1kHz
  • Bass Boost:
  • 0dB ~ 12dB @ 50Hz
  • Operating Voltage:
  • 9V ~ 16V
  • Signal-Noise Ratio:
  • 1Ω: 93.7dB
  • 2Ω: 95dB
  • 4Ω: 93.4dB
  • Input Sensitivity:
  • 0.2V ~ 2V
  • Current Draw (Music):
  • 1Ω: 75A
  • 2Ω: 71A
  • 4Ω: 69.4A
  • Current Draw (Max):
  • 1Ω: 149A
  • 2Ω: 143A
  • 4Ω: 138.8A
  • Total Efficiency:
  • 1Ω: 85%
  • 2Ω: 89%
  • 4Ω: 91.5%
  • Damping Factor:
  • 2000
  • Power Cable:
  • 16mm² (5 AWG)
  • Audio Output Cable:
  • 2 x 1.5 mm² (15 AWG)
  • Recommended Fuse (Music):
  • 80A
  • Recommended Battery:
  • 80Ah
  • Width:
  • 13.6 cm / 5.4 in
  • Length:
  • 18 cm / 7.1 in
  • Height:
  • 5.48 cm / 2.1 in
  • Weight:
  • 1.13 Kg.
