SounDigital 8000.1 EVO5 1 Ohm

The 8000.1 EVO 5 is a compact and modern amplifier that delivers 8000W RMS of power in 1 channel.

Incorporated with the innovative MCPCB board. Increasing your efficiency and ensuring much more consistent performance.

Teknisk information

• Compatible with SD-RLC Remote level control.
• Power @ 4Ω: 1 X 3844 WRMS
• Power @ 2Ω: 1 X 5360 WRMS
• Power @ 1Ω: 1 X 8000 WRMS
• Frequency Response (-3dB):
• 8Hz ~ 20kHz
• Subsonic (12dB/oct):
• 8Hz ~ 80Hz
• Low Pass filter (12dB/oct):
• 50Hz ~ 20kHz
• Bass Boost:
• 0dB ~ 12dB @ 50Hz
• Operating Voltage:
• 9V ~ 16V
• SNR
• @ 1Ω: 92dB
• @ 2Ω: 85dB
• Input Sensitivity (RCA):
• 0.2V ~ 2V
• Input Sensitivity (High Level input):
• 1.3V ~ 15V
• Current Draw (music):
• 381A
• Current Draw (max.)
• 762A
• Total Efficiency:
• 80%
• Damping Factor (@100Hz nominal impedance)
• 2000
• Power Cable:
• 70mm² (00 AWG)
• Speaker Cable
• 2 x 10mm² (7 AWG)
• Recommended Fuse (music):
• 2 x 200A
• Recommended battery (minimum):
• 2 x 220Ah
• Width:
• 7.1″ / 18 cm
• Length:
• 12.2″ / 31 cm
• Height:
• 2.5″ / 6.32 cm
• Weight:
• 8.79 lb / 3.99 kg
• Koppla inte förstärkaren under angiven nominell impedans!
• Do not run your amp under rated impedance!.
