SounDigital 400.4 EVO 6 - 4 Ohm

It′s not just about audio.

It′s sensation, technology and emotion. IT′S EVO6. This isn′t just another amplifier, it′s a leap in the evolution of car audio.

It redefines amplifier design. Every detail has been redesigned for excellence in audio quality, making your musical perception much more immersive.

Introducing the new 400.4 EVO6. With the help of AI we have achieved a miniaturization never seen before, these are the smallest amplifiers in the world, breaking power density records.

High efficiency that fits anywhere. Join us on a journey into the future.

Teknisk information

• POWER RATING
• 12,6V: @ 2Ω: 4 x 100 W RMS
• 12,6V: @ 4Ω: 4 x 66 W RMS
• 12,6V: @ 4Ω 2 x 200 W RMS ( Bridge )
• 14,4V: @ 2Ω: 4 x 140 W RMS
• 14,4V: @ 4Ω: 4 x 75 W RMS
• Frequency Response (-3dB): 8Hz ~ 20kHz
• Low Pass filter (12dB/octave): 80Hz
• High Pass filter (12dB/octave): 80Hz
• Operating Voltage: 9V ~ 16V
• SNR: 94dB
• Input Sensitivity (RCA): 0.2V ~ 2V
• Current Draw (music): 20A
• Current Draw (max.): 40.5A
• Total Efficiency: 78%
• Damping Factor (@100Hz nominal impedance): 200
• Power Cable: 6mm² (9 AWG)
• Speaker Cable: 2 x 1.5mm² (15 AWG)
• Recommended Fuse (music): 25A
• Recommended Battery (minimum): 40Ah
• Width: 3.4″ / 8.6 cm
• Length: 4.2″ / 10.7 cm
• Height: 1.8″ / 4.6 cm
• Weight: 0,437 kg / 0.963 lb
• Koppla inte förstärkaren under angiven nominell impedans!
• Do not run your amp under rated impedance!
