Product Specifications | |
|---|---|
| Nominal Diameter | 18" |
| Bolt Circle Diameter | 17.32 |
| Moving Mass Of Diaphragm (Mmd) | 348 |
| Power Handling (RMS) | 1700 Watts |
| Power Handling (MAX) | 3400 Watts |
| Impedance | 4? |
| Frequency Response | 30 to 500Hz |
| Sensitivity | 97dB 2.83V/1m |
| Voice Coil Diameter | 4.5" |
Thiele-Small Parameters | |
|---|---|
| Resonant Frequency (Fs) | 30Hz |
| DC Resistance (Re) | 3.3? |
| Voice Coil Inductance (Le) | 2.8mH |
| Mechanical Q (Qms) | 4.75 |
| Electromagnetic Q (Qes) | 0.18 |
| Total Q (Qts) | 0.17 |
| Compliance Equivalent Volume (Vas) | 6.25ft³ |
| Mechanical Compliance of Suspension (Cms) | 0.0809mm/N |
| BL Product (BL) | 34.68T·m |
| Maximum Linear Excursion (Xmax) | 16.5mm |
| Surface Area of Cone (Sd) | 1241cm² |
Materials of Construction | |
|---|---|
| Cone Material | Treated Paper |
| Surround Material | Cloth |
| Voice Coil Wire Material | CCA |
| Voice Coil Former | Fiberglass |
| Basket / Frame Material | Cast Aluminum |
| Magnet Material | Neodymium |
