Speaker Size | 6.5” |
---|---|
Nominal Impedance (ohms) | N/A |
RMS Power Rating | 100W RMS |
Max Power Rating | 200W MAX |
Voice Coil Diameter (inch/mm) | 1.75" |
Types | Full Range |
SPL (db) | 93.2 |
Re (Ω)[series] | 3.47 |
Qms | 9.96 |
Qes | 0.58 |
Qts | 0.55 |
Fs-Free Air Resonance (Hz) | 128.1 |
Vas (Liter) | 3.62 |
Cms (mm/N) | 0.136 |
Mms (g) | 11.3 |
Sd (cm²) | 0.0137 |
BL (T*M) | 7.41 |
Xmax - Inch(mm) | 1.3 |
Pwr (W) NOM/MAX | 100/200 |
Over-All Diameter | 7.08”(180mm) |
Total Diameter | 7.08 (180) in.(mm) |
Mounting Diameter (inch/mm) | 5.76 (146.4) in.(mm) |
Mounting Depth | 2.93 (74.5) in.(mm) |
Total Depth | 3.74 (95) in.(mm) |
Grille | Yes |
