TECHNICAL SPECIFICATIONS
Nominal impedance
8 Ohm
Power capacity
220 W AES
Nominal diameter
165 mm 6.5 in
Sensitivity
94 dB 1 W/1 m @ ZN
Minimum impedance
6.7 ohm
Frequency range
95-8000 Hz
Program power
440 W
Recommended enclosure volume
9 l
Voice coil diameter
38.1 mm 1.5 in
BL factor
9.4 N/A
Moving mass
0.013 kg
Winding length
14 mm
Air gap height
6 mm
Xdamage pp
30 mm
PARAMETERS THIELE & SMALL
Fs
90 Hz
Re
5.3 ohm
Qms
1.4
Qes
0.45
Qts
0.34
Vas
6.5 l
Cms
235 µm / N
Rms
5.5 kg / s
Efficiency %
1
Sd
0.014 m²
Xmax
5.7 mm
Vd
80 cm³
Le @1 kHz
0.5 mH
CONSTRUCTION DETAILS
Depth
80 mm 3.1 in
Net weight
2.2 kg 4.84 lb
Total weight
2.3 kg 5.06 lb
Magnet
Ferrite
