TECHNICAL SPECIFICATIONS
Nominal impedance
8 Ohm
Power capacity
300 W AES
Nominal diameter
250 mm 10 in
Sensitivity
95 dB 1 W @ 1m @ 2π
Minimum impedance
6.5 ohm
Frequency range
55-5000 Hz
Program power
600 W
Recommended enclosure volume
15 / 50 l 0.53 / 1.77 ft.³
Voice coil diameter
50.8 mm 2 in
BL factor
14.2 N/A
Moving mass
0.039 kg
Winding length
15 mm
Air gap height
8 mm
Xdamage pp
30 mm
PARAMETERS THIELE & SMALL
Fs
52 Hz
Re
6.1 ohm
Qms
3.9
Qes
0.39
Qts
0.35
Vas
42 l
Cms
240 µm / N
Rms
3.3 kg / s
Efficiency %
1.5
Sd
0.035 m²
Xmax
6 mm
Vd
210 cm³
Le @1 kHz
1 mH
CONSTRUCTION DETAILS
Depth
117 mm 4.6 in
Net weight
3.5 kg 7.7 lb
Total weight
3.9 kg 8.6 lb
Magnet
Ferrite
