TECHNICAL SPECIFICATIONS
Nominal impedance
8 Ohm
Power capacity
150 W AES
Nominal diameter
127 mm 5 in
Sensitivity
92 dB 1 W @ 1 m
Minimum impedance
6.7 ohm
Frequency range
70-10000 Hz
Program power
300 W
Voice coil diameter
38 mm 1.5 in
BL factor
9.9 N/A
Moving mass
0.011 Kg
Winding length
14 mm
Air gap height
6 mm
PARAMETERS THIELE & SMALL
Fs
78 Hz
Re
5.3 ohm
Qms
10.7
Qes
0.31
Qts
0.3
Vas
4.5 l
Cms
355 µm / N
Rms
0.5 kg/s
Efficiency %
0.68
Sd
0.0095 m²
Xmax
5.7 mm
Vd
54.15 cm³
Le @1 kHz
0.25 mH
CONSTRUCTION DETAILS
Depth
71 mm 2.79 in
Net weight
1.24kg 2.73 lb
Magnet
Neodymium
