TECHNICAL SPECIFICATIONS
Throat diameter
25.4 mm 1 in
Nominal impedance
8 Ohm
Minimum impedance
5.8 ohm
Re
5.1 ohm
Power capacity
20 W AES above 2 kHz
Program power
40 W above 2 kHz
Sensitivity
110 dB 1W / 1m @ ZN acoplado a bocina TD-164
Frequency range
1000-20000 Hz
Recom. crossover frequency
2 kHz or higher (12dB/oct min slope)
Voice coil diameter
25.4 mm 1 in
Flux density
1.85 T
Diaphragm material
Polyamide
CONSTRUCTION DETAILS
External diameter
64 mm2.52 in
Depth
38 mm 1.49 in
Mounting
Three M5 threaded holes. 120º apart on
57 mm (2.24 in) diameter circle.
Two M4 threaded holes. 180º apart on
53 mm (2.08 in) diameter circle.
Net weight
0.4 kg 0.9 lb
Total weight
0.5 kg 1.1 lb
Magnet
Neodymium
