SounDigital 2000.2 EVO 5 - 4 Ohm

SounDigital 2000.2 EVO 5 - 4 Ohm

Power @ 1?: N/A Power @ 2?: 2 X 1000W Bridge Power @ 2?: N/A Bridge Power @ 4?: 1 X 1200W Frequency Response ( - 3dB): 10Hz ~ 20kHz Low Pass Filter (LP - 12dB/8): 80Hz High Pass Filter (HP - 12dB/8): 80Hz Operating Voltage: 8V ~ 16V SNR: 90dB Input Sensitivity: 0.2 ~ 4V Current Draw (Music): 2?: 89A 4?: 88A Current Draw With Resistive Load (1kHz @ 12.6V): 2?: 178A 4?: 176A Total Efficiency: 2?: 89% 4?: 90% Damping Factor (@100Hz Rated Impedance): 200 Minimum Audio Output Impedance: 2?: 1 ohm 4?: 2 ohms Minimum Bridge Impedance: 2?: 2 ohm 4?: 4 ohms Recommended Fuse (Music): 100A Recommended Battery (Music): 100Ah Width: 5.4 in / 13,6 cm Length: 8.9 in / 22,7 cm Height: 2.2 in / 5,5 cm Weight: 3.39 lb / 1,54 Kg.
