TECHNICAL SPECIFICATIONS
Nominal impedance
8 Ohm
Power capacity
50 W RMS
Nominal diameter
125 mm 5 in
Sensitivity
88 dB 1 W @ 1 m @ ZN
Minimum impedance
5.5 ohm
Frequency range
65-12000 Hz
Program power
100 W
Recommended enclosure volume
8 l
Voice coil diameter
25.4 mm 1 in
BL factor
6.4 N / A
Moving mass
0.011 Kg
Winding length
14 mm
Air gap height
6 mm
Xdamage pp
20 mm
PARAMETERS THIELE & SMALL
Fs
63 Hz
Re
5.33 ohm
Qms
2.3
Qes
0.58
Qts
0.46
Vas
5.8 l
Cms
564 µm / N
Rms
2 kg/s
Efficiency %
0.25
Sd
0.0085 m²
Xmax
5.5 mm
Vd
46 cm³
Le @1 kHz
0.2 mH
CONSTRUCTION DETAILS
Net weight
1.2 kg 2.64 Ib.
Total weight
1.3 kg 2.86 lb
Magnet
Ferrite
