Product Specifications | |
|---|---|
| Nominal Diameter | 12" |
| Bolt Circle Diameter | 11.6 |
| Moving Mass Of Diaphragm (Mmd) | 74 |
| Power Handling (RMS) | 450 Watts |
| Power Handling (MAX) | 900 Watts |
| Impedance | 8? |
| Frequency Response | 40 to 1,000Hz |
| Sensitivity | 95dB 2.83V/1m |
| Voice Coil Diameter | 3" |
Thiele-Small Parameters | |
|---|---|
| Resonant Frequency (Fs) | 42Hz |
| DC Resistance (Re) | 6.1? |
| Voice Coil Inductance (Le) | 2mH |
| Mechanical Q (Qms) | 3.8 |
| Electromagnetic Q (Qes) | 0.22 |
| Total Q (Qts) | 0.2 |
| Compliance Equivalent Volume (Vas) | 2.6ft³ |
| BL Product (BL) | 23.5T·m |
| Maximum Linear Excursion (Xmax) | 7mm |
| Surface Area of Cone (Sd) | 522cm² |
Materials of Construction | |
|---|---|
| Cone Material | Coated Paper |
| Surround Material | Cloth |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Fiberglass |
| Basket / Frame Material | Cast Aluminum |
| Magnet Material | Ferrite |
