- High quality 2 way component system
- Klippel® optimized midwoofer with aluminum cone
- Nomex spider
- Copper cap for impedance linearizing
- Resonance free steel basket
- 1″ titanium dome tweeter with slant tweeter housing
- Separated tweeter and midwoofer 12dB crossovers for easy install
- Midwoofer crossover integrated to the midwoofer frame
Diameter of midwoofer or midrange : 165 mm / 6.5″
Mounting diameter of midwoofer or midrange: 142.5 mm / 5.61″
Mounting depth of midwoofer or midrange: 68 mm / 2.68″
Voice coil of midwoofer or midrange: 25 mm / 1″
Cone of midwoofer or midrange: Aluminum
Dustcap / Phaseplug of midwoofer or midrange: Aluminum
Basket of midwoofer or midrange: Euro-Din steel GZ basket
Magnet of midwoofer or midrange: Ferrit
Diameter of tweeter49.5 mm / 1.95″
Mounting diameter of tweeter: 44 mm / 1.95″
Mounting depth of tweeter: 10 mm / 0.39″
Voice coil of tweeter: 25 mm / 1″
Cone of tweeter: Titanium
Housing of tweeter: Machined aluminum
Magnet of tweeter: Neodymium
Power handling : WRMS120
Power handling : W peak190
Impedance: 3 Ohm
SPL: 89 dB (Mid) / 92 dB (Tw)
Frequency response: 35 Hz - 4 kHz (Mid) / 3 - 26 kHz (Tw)
Grilles are NOT included for woofers
